Mobile Communication Lab

Setup with AWG and oscilloscope
Measurement setup comprising Keysight arbitrary waveform generator and oscilloscope for multi-gigabit communication experiments (Photo: Eisenbeis, KIT).
USRP setup
Software Defined Radios in a MIMO setup (Photo: Nuß, KIT)

This laboratory is dedicated to testing of mobile communication systems as well as standard microwave components and systems up to 40GHz. The lab is equipped with:

  • network analyzers, spectrum analyzers, signal generators, noise sources etc. up to 40 GHz
  • oscilloscopes up to 80 GS/s, arbitrary wave form generators up to 20 GS/s
  • software defined radio platforms up to 4.4 GHz, also MIMO capable
